EPON 16 Port OLT Layer 3 Support Up To 1024 ONU 64 ONU Per PON Port

Name: EPON 16 Port OLT Layer 3 Support Up To 1024 ONU 64 ONU Per PON Port
Brand: ZIKUN
Price: 1 USD

EPON 16 Port OLT Layer 3 Support Up To 1024 ONU 64 ONU Per PON Port Manufactures

Brand Name : ZIKUN

Model Number : ZC-P1016E

MOQ : 1

Price : Negotiable

Payment Terms : T/T

Delivery Time : 5-15 work days

High Light : EPON 16 Port OLT, Layer 3 16 Port OLT, V1600D16 Layer 3 OLT

Product Name : Layer3 16 Ports EPON OLT

Dimension : 445mm×321mm×46mm (L×W×H)

Wavelength : Tx1310nm, R x 1490nm

Power Supply : AC 100~240 V, 50/60 Hz

Power Consumption : ≤85W

Contact Now

ZIKUN EPON 16 Port OLT Layer 3 Support Up To 1024 ONU 64 ONU Per PON Port

Product Description

ZC-P1016E EPON OLT is 1U height 19 inch rack mount products. The features of the OLT are small, convenient, flexible, easy to deploy, high performance. It is appropriate to be deployed in compact room environment. The OLTs can be used for “Triple-Play”, VPN, IP Camera, Enterprise LAN and ICT applications.

ZC-P1016E EPON OLT provides 16 EPON ports, 8GE copper RJ45 Ethernet ports and 4*GE(SFP)/4*10GE(SFP+). It has high reliability, high density and powerful switching and routing abilities. It is a new generation of broadband and multi-service access OLT devices oriented towards the service-integrated network.

ZIKUN EPON OLT ZC-P1016E
Small and Flexible | High Performance | Easy to Deploy EPON 16 Port OLT Layer 3 Support Up To 1024 ONU 64 ONU Per PON Port

Technical Specifications

Parameter	Specifications
PON standard	EPON ITU-T G.984.x
PON interface	16*GPON SFP Ports (Class C+), Receiving sensitivity: ≤ -30d Bm(Saturation Optical - 12d Bm). Power,Transmitting optical power: +3 ~ +7d BmTransmission distance: 20KM. Max splitting ratio1:128
PON interface	Upstream 2.488G ,Downstream 1.244G
Wavelength	Tx1310nm, R x 1490nm
Uplink	8*copper Ethernet ports 10/100/1000M auto-negotiation
Uplink	4GE(SFP)/ 410GE (SFP+) auto-detection
Layer 3	Support static route, RIP v1/v2, OSFP v2, ARP proxy
Management Ports	110/ 100BASE-T out-band port, 1CONSOLE port
Management Mode	SNMP, Telnet, CLI, WEB
VLAN	Tag / Un-tag,VLAN transmission,QinQ
Operating condition	Operating temp: -5 C~ +55C
Storing condition	Storing temp: -40C ~ +85C
Humidity	5~90%(non-condensing)
Power consumption	≤85W
Dimension	445mm×321mm×46mm (L×W×H)
Net weight	5.25Kg

Product Tags:

EPON 16 Port OLT

Layer 3 16 Port OLT

EPON 16 Port OLT Layer 3 Support Up To 1024 ONU 64 ONU Per PON Port Images
